IBYR 210-222 A2E18

Name: IBYR 210-222 A2E18
Brand: Arpol

Details

Outside Diameter160–400 mm

Pressure11–23 bar

Length140 mm

Casing qualityW5, W4

Sealing gasketSILICONE, NBR, EPDM

Ask for quote Configure

Catalogue Installation instructions Fitting instruction

ODmm	Pressurebar	Gasket	Quality	T max°C
156–168	23	EPDM	W4	100
156–168	23	EPDM	W5	100
156–168	23	NBR	W4	80
156–168	23	NBR	W5	80
156–168	23	SILICONE	W4	200
156–168	23	SILICONE	W5	200
166–178	23	EPDM	W4	100
166–178	23	EPDM	W5	100
166–178	23	NBR	W4	80
166–178	23	NBR	W5	80
166–178	23	SILICONE	W4	200
166–178	23	SILICONE	W5	200
173–185	23	EPDM	W4	100
173–185	23	EPDM	W5	100
173–185	23	NBR	W4	80
173–185	23	NBR	W5	80
173–185	23	SILICONE	W4	200
173–185	23	SILICONE	W5	200
186–198	23	EPDM	W4	100
186–198	23	EPDM	W5	100
186–198	23	NBR	W4	80
186–198	23	NBR	W5	80
186–198	23	SILICONE	W4	200
186–198	23	SILICONE	W5	200
194–206	23	EPDM	W4	100
194–206	23	EPDM	W5	100
194–206	23	NBR	W4	80
194–206	23	NBR	W5	80
194–206	23	SILICONE	W4	200
194–206	23	SILICONE	W5	200
202–214	18	EPDM	W4	100
202–214	18	EPDM	W5	100
202–214	18	NBR	W4	80
202–214	18	NBR	W5	80
202–214	18	SILICONE	W4	200
202–214	18	SILICONE	W5	200
217–229	18	EPDM	W4	100
217–229	18	EPDM	W5	100
217–229	18	NBR	W4	80
217–229	18	NBR	W5	80
217–229	18	SILICONE	W4	200
217–229	18	SILICONE	W5	200
231–243	18	EPDM	W4	100
231–243	18	EPDM	W5	100
231–243	18	NBR	W4	80
231–243	18	NBR	W5	80
231–243	18	SILICONE	W4	200
231–243	18	SILICONE	W5	200
242–254	18	EPDM	W4	100
242–254	18	EPDM	W5	100
242–254	18	NBR	W4	80
242–254	18	NBR	W5	80
242–254	18	SILICONE	W4	200
242–254	18	SILICONE	W5	200
248–260	18	EPDM	W4	100
248–260	18	EPDM	W5	100
248–260	18	NBR	W4	80
248–260	18	NBR	W5	80
248–260	18	SILICONE	W4	200
248–260	18	SILICONE	W5	200
265–277	19	EPDM	W4	100
265–277	19	EPDM	W5	100
265–277	19	NBR	W4	80
265–277	19	NBR	W5	80
265–277	19	SILICONE	W4	200
265–277	19	SILICONE	W5	200
271–283	15	EPDM	W4	100
271–283	15	EPDM	W5	100
271–283	15	NBR	W4	80
271–283	15	NBR	W5	80
271–283	15	SILICONE	W4	200
271–283	15	SILICONE	W5	200
271–283	19	EPDM	W4	100
271–283	19	EPDM	W5	100
271–283	19	NBR	W4	80
271–283	19	NBR	W5	80
271–283	19	SILICONE	W4	200
271–283	19	SILICONE	W5	200
279–291	15	EPDM	W4	100
279–291	15	EPDM	W5	100
279–291	15	NBR	W4	80
279–291	15	NBR	W5	80
279–291	15	SILICONE	W4	200
279–291	15	SILICONE	W5	200
279–291	19	EPDM	W4	100
279–291	19	EPDM	W5	100
279–291	19	NBR	W4	80
279–291	19	NBR	W5	80
279–291	19	SILICONE	W4	200
279–291	19	SILICONE	W5	200
292–304	15	EPDM	W4	100
292–304	15	EPDM	W5	100
292–304	15	NBR	W4	80
292–304	15	NBR	W5	80
292–304	15	SILICONE	W4	200
292–304	15	SILICONE	W5	200
292–304	19	EPDM	W4	100
292–304	19	EPDM	W5	100
292–304	19	NBR	W4	80
292–304	19	NBR	W5	80
292–304	19	SILICONE	W4	200
292–304	19	SILICONE	W5	200
298–310	19	EPDM	W4	100
298–310	19	EPDM	W5	100
298–310	19	NBR	W4	80
298–310	19	NBR	W5	80
298–310	19	SILICONE	W4	200
298–310	19	SILICONE	W5	200
310–322	12	EPDM	W4	100
310–322	12	EPDM	W5	100
310–322	12	NBR	W4	80
310–322	12	NBR	W5	80
310–322	12	SILICONE	W4	200
310–322	12	SILICONE	W5	200
310–322	16	EPDM	W4	100
310–322	16	EPDM	W5	100
310–322	16	NBR	W4	80
310–322	16	NBR	W5	80
310–322	16	SILICONE	W4	200
310–322	16	SILICONE	W5	200
320–332	12	EPDM	W4	100
320–332	12	EPDM	W5	100
320–332	12	NBR	W4	80
320–332	12	NBR	W5	80
320–332	12	SILICONE	W4	200
320–332	12	SILICONE	W5	200
320–332	16	EPDM	W4	100
320–332	16	EPDM	W5	100
320–332	16	NBR	W4	80
320–332	16	NBR	W5	80
320–332	16	SILICONE	W4	200
320–332	16	SILICONE	W5	200
329–341	12	EPDM	W4	100
329–341	12	EPDM	W5	100
329–341	12	NBR	W4	80
329–341	12	NBR	W5	80
329–341	12	SILICONE	W4	200
329–341	12	SILICONE	W5	200
329–341	16	EPDM	W4	100
329–341	16	EPDM	W5	100
329–341	16	NBR	W4	80
329–341	16	NBR	W5	80
329–341	16	SILICONE	W4	200
329–341	16	SILICONE	W5	200
338–350	12	EPDM	W4	100
338–350	12	EPDM	W5	100
338–350	12	NBR	W4	80
338–350	12	NBR	W5	80
338–350	12	SILICONE	W4	200
338–350	12	SILICONE	W5	200
338–350	16	EPDM	W4	100
338–350	16	EPDM	W5	100
338–350	16	NBR	W4	80
338–350	16	NBR	W5	80
338–350	16	SILICONE	W4	200
338–350	16	SILICONE	W5	200
349–361	12	EPDM	W4	100
349–361	12	EPDM	W5	100
349–361	12	NBR	W4	80
349–361	12	NBR	W5	80
349–361	12	SILICONE	W4	200
349–361	12	SILICONE	W5	200
349–361	16	EPDM	W4	100
349–361	16	EPDM	W5	100
349–361	16	NBR	W4	80
349–361	16	NBR	W5	80
349–361	16	SILICONE	W4	200
349–361	16	SILICONE	W5	200
359–371	18	EPDM	W4	100
359–371	18	EPDM	W5	100
359–371	18	NBR	W4	80
359–371	18	NBR	W5	80
359–371	18	SILICONE	W4	200
359–371	18	SILICONE	W5	200
372–384	11	EPDM	W4	100
372–384	11	EPDM	W5	100
372–384	11	NBR	W4	80
372–384	11	NBR	W5	80
372–384	11	SILICONE	W4	200
372–384	11	SILICONE	W5	200
372–384	18	EPDM	W4	100
372–384	18	EPDM	W5	100
372–384	18	NBR	W4	80
372–384	18	NBR	W5	80
372–384	18	SILICONE	W4	200
372–384	18	SILICONE	W5	200
379–391	11	EPDM	W4	100
379–391	11	EPDM	W5	100
379–391	11	NBR	W4	80
379–391	11	NBR	W5	80
379–391	11	SILICONE	W4	200
379–391	11	SILICONE	W5	200
379–391	18	EPDM	W4	100
379–391	18	EPDM	W5	100
379–391	18	NBR	W4	80
379–391	18	NBR	W5	80
379–391	18	SILICONE	W4	200
379–391	18	SILICONE	W5	200
394–406	11	EPDM	W4	100
394–406	11	EPDM	W5	100
394–406	11	NBR	W4	80
394–406	11	NBR	W5	80
394–406	11	SILICONE	W4	200
394–406	11	SILICONE	W5	200
394–406	18	EPDM	W4	100
394–406	18	EPDM	W5	100
394–406	18	NBR	W4	80
394–406	18	NBR	W5	80
394–406	18	SILICONE	W4	200
394–406	18	SILICONE	W5	200

OD (mm)
156–168
Pressure (bar)
23
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
156–168
Pressure (bar)
23
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
156–168
Pressure (bar)
23
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
156–168
Pressure (bar)
23
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
156–168
Pressure (bar)
23
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
156–168
Pressure (bar)
23
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
166–178
Pressure (bar)
23
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
166–178
Pressure (bar)
23
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
166–178
Pressure (bar)
23
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
166–178
Pressure (bar)
23
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
166–178
Pressure (bar)
23
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
166–178
Pressure (bar)
23
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
173–185
Pressure (bar)
23
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
173–185
Pressure (bar)
23
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
173–185
Pressure (bar)
23
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
173–185
Pressure (bar)
23
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
173–185
Pressure (bar)
23
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
173–185
Pressure (bar)
23
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
186–198
Pressure (bar)
23
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
186–198
Pressure (bar)
23
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
186–198
Pressure (bar)
23
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
186–198
Pressure (bar)
23
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
186–198
Pressure (bar)
23
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
186–198
Pressure (bar)
23
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
194–206
Pressure (bar)
23
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
194–206
Pressure (bar)
23
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
194–206
Pressure (bar)
23
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
194–206
Pressure (bar)
23
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
194–206
Pressure (bar)
23
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
194–206
Pressure (bar)
23
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
202–214
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
202–214
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
202–214
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
202–214
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
202–214
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
202–214
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
217–229
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
217–229
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
217–229
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
217–229
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
217–229
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
217–229
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
231–243
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
231–243
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
231–243
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
231–243
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
231–243
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
231–243
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
242–254
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
242–254
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
242–254
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
242–254
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
242–254
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
242–254
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
248–260
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
248–260
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
248–260
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
248–260
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
248–260
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
248–260
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
265–277
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
265–277
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
265–277
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
265–277
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
265–277
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
265–277
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
15
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
15
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
15
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
15
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
15
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
15
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
15
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
15
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
15
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
15
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
15
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
15
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
292–304
Pressure (bar)
15
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
292–304
Pressure (bar)
15
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
292–304
Pressure (bar)
15
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
292–304
Pressure (bar)
15
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
292–304
Pressure (bar)
15
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
292–304
Pressure (bar)
15
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
292–304
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
292–304
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
292–304
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
292–304
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
292–304
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
292–304
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
298–310
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
298–310
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
298–310
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
298–310
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
298–310
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
298–310
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
359–371
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
359–371
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
359–371
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
359–371
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
359–371
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
359–371
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
379–391
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
379–391
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
379–391
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
379–391
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
379–391
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
379–391
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
379–391
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
379–391
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
379–391
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
379–391
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
379–391
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
379–391
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200

IBYR 210-222 A2E18

Details

Downloads
