IBWR 320-332 A2E12

Name: IBWR 320-332 A2E12
Brand: Arpol

Details

Outside Diameter267–493 mm

Pressure8–19 bar

Length300 mm

Casing qualityW5, W4

Sealing gasketSILICONE, NBR, EPDM

Ask for quote Configure

Catalogue Installation instructions Fitting instruction

ODmm	Pressurebar	Gasket	Quality	T max°C
265–277	19	EPDM	W4	100
265–277	19	EPDM	W5	100
265–277	19	NBR	W4	80
265–277	19	NBR	W5	80
265–277	19	SILICONE	W4	200
265–277	19	SILICONE	W5	200
271–283	15	EPDM	W4	100
271–283	15	EPDM	W5	100
271–283	15	NBR	W4	80
271–283	15	NBR	W5	80
271–283	15	SILICONE	W4	200
271–283	15	SILICONE	W5	200
271–283	19	EPDM	W4	100
271–283	19	EPDM	W5	100
271–283	19	NBR	W4	80
271–283	19	NBR	W5	80
271–283	19	SILICONE	W4	200
271–283	19	SILICONE	W5	200
279–291	15	EPDM	W4	100
279–291	15	EPDM	W5	100
279–291	15	NBR	W4	80
279–291	15	NBR	W5	80
279–291	15	SILICONE	W4	200
279–291	15	SILICONE	W5	200
279–291	19	EPDM	W4	100
279–291	19	EPDM	W5	100
279–291	19	NBR	W4	80
279–291	19	NBR	W5	80
279–291	19	SILICONE	W4	200
279–291	19	SILICONE	W5	200
292–304	15	EPDM	W4	100
292–304	15	EPDM	W5	100
292–304	15	NBR	W4	80
292–304	15	NBR	W5	80
292–304	15	SILICONE	W4	200
292–304	15	SILICONE	W5	200
298–310	19	EPDM	W4	100
298–310	19	EPDM	W5	100
298–310	19	NBR	W4	80
298–310	19	NBR	W5	80
298–310	19	SILICONE	W4	200
298–310	19	SILICONE	W5	200
310–322	12	EPDM	W4	100
310–322	12	EPDM	W5	100
310–322	12	NBR	W4	80
310–322	12	NBR	W5	80
310–322	12	SILICONE	W4	200
310–322	12	SILICONE	W5	200
310–322	16	EPDM	W4	100
310–322	16	EPDM	W5	100
310–322	16	NBR	W4	80
310–322	16	NBR	W5	80
310–322	16	SILICONE	W4	200
310–322	16	SILICONE	W5	200
320–332	12	EPDM	W4	100
320–332	12	EPDM	W5	100
320–332	12	NBR	W4	80
320–332	12	NBR	W5	80
320–332	12	SILICONE	W4	200
320–332	12	SILICONE	W5	200
320–332	16	EPDM	W4	100
320–332	16	EPDM	W5	100
320–332	16	NBR	W4	80
320–332	16	NBR	W5	80
320–332	16	SILICONE	W4	200
320–332	16	SILICONE	W5	200
329–341	12	EPDM	W4	100
329–341	12	EPDM	W5	100
329–341	12	NBR	W4	80
329–341	12	NBR	W5	80
329–341	12	SILICONE	W4	200
329–341	12	SILICONE	W5	200
329–341	16	EPDM	W4	100
329–341	16	EPDM	W5	100
329–341	16	NBR	W4	80
329–341	16	NBR	W5	80
329–341	16	SILICONE	W4	200
329–341	16	SILICONE	W5	200
338–350	12	EPDM	W4	100
338–350	12	EPDM	W5	100
338–350	12	NBR	W4	80
338–350	12	NBR	W5	80
338–350	12	SILICONE	W4	200
338–350	12	SILICONE	W5	200
338–350	16	EPDM	W4	100
338–350	16	EPDM	W5	100
338–350	16	NBR	W4	80
338–350	16	NBR	W5	80
338–350	16	SILICONE	W4	200
338–350	16	SILICONE	W5	200
349–361	12	EPDM	W4	100
349–361	12	EPDM	W5	100
349–361	12	NBR	W4	80
349–361	12	NBR	W5	80
349–361	12	SILICONE	W4	200
349–361	12	SILICONE	W5	200
349–361	16	EPDM	W4	100
349–361	16	EPDM	W5	100
349–361	16	NBR	W4	80
349–361	16	NBR	W5	80
349–361	16	SILICONE	W4	200
349–361	16	SILICONE	W5	200
359–371	18	EPDM	W4	100
359–371	18	EPDM	W5	100
359–371	18	NBR	W4	80
359–371	18	NBR	W5	80
359–371	18	SILICONE	W4	200
359–371	18	SILICONE	W5	200
372–384	11	EPDM	W4	100
372–384	11	EPDM	W5	100
372–384	11	NBR	W4	80
372–384	11	NBR	W5	80
372–384	11	SILICONE	W4	200
372–384	11	SILICONE	W5	200
372–384	18	EPDM	W4	100
372–384	18	EPDM	W5	100
372–384	18	NBR	W4	80
372–384	18	NBR	W5	80
372–384	18	SILICONE	W4	200
372–384	18	SILICONE	W5	200
379–391	11	EPDM	W4	100
379–391	11	EPDM	W5	100
379–391	11	NBR	W4	80
379–391	11	NBR	W5	80
379–391	11	SILICONE	W4	200
379–391	11	SILICONE	W5	200
394–406	11	EPDM	W4	100
394–406	11	EPDM	W5	100
394–406	11	NBR	W4	80
394–406	11	NBR	W5	80
394–406	11	SILICONE	W4	200
394–406	11	SILICONE	W5	200
394–406	18	EPDM	W4	100
394–406	18	EPDM	W5	100
394–406	18	NBR	W4	80
394–406	18	NBR	W5	80
394–406	18	SILICONE	W4	200
394–406	18	SILICONE	W5	200
402–414	13	EPDM	W4	100
402–414	13	EPDM	W5	100
402–414	13	NBR	W4	80
402–414	13	NBR	W5	80
402–414	13	SILICONE	W4	200
402–414	13	SILICONE	W5	200
410–422	9	EPDM	W4	100
410–422	9	EPDM	W5	100
410–422	9	NBR	W4	80
410–422	9	NBR	W5	80
410–422	9	SILICONE	W4	200
410–422	9	SILICONE	W5	200
410–422	13	EPDM	W4	100
410–422	13	EPDM	W5	100
410–422	13	NBR	W4	80
410–422	13	NBR	W5	80
410–422	13	SILICONE	W4	200
410–422	13	SILICONE	W5	200
410–422	16	EPDM	W4	100
410–422	16	EPDM	W5	100
410–422	16	NBR	W4	80
410–422	16	NBR	W5	80
410–422	16	SILICONE	W4	200
410–422	16	SILICONE	W5	200
425–437	9	EPDM	W4	100
425–437	9	EPDM	W5	100
425–437	9	NBR	W4	80
425–437	9	NBR	W5	80
425–437	9	SILICONE	W4	200
425–437	9	SILICONE	W5	200
425–437	13	EPDM	W4	100
425–437	13	EPDM	W5	100
425–437	13	NBR	W4	80
425–437	13	NBR	W5	80
425–437	13	SILICONE	W4	200
425–437	13	SILICONE	W5	200
425–437	16	EPDM	W4	100
425–437	16	EPDM	W5	100
425–437	16	NBR	W4	80
425–437	16	NBR	W5	80
425–437	16	SILICONE	W4	200
425–437	16	SILICONE	W5	200
433–445	9	EPDM	W4	100
433–445	9	EPDM	W5	100
433–445	9	NBR	W4	80
433–445	9	NBR	W5	80
433–445	9	SILICONE	W4	200
433–445	9	SILICONE	W5	200
433–445	13	EPDM	W4	100
433–445	13	EPDM	W5	100
433–445	13	NBR	W4	80
433–445	13	NBR	W5	80
433–445	13	SILICONE	W4	200
433–445	13	SILICONE	W5	200
433–445	16	EPDM	W4	100
433–445	16	EPDM	W5	100
433–445	16	NBR	W4	80
433–445	16	NBR	W5	80
433–445	16	SILICONE	W4	200
433–445	16	SILICONE	W5	200
442–454	9	EPDM	W4	100
442–454	9	EPDM	W5	100
442–454	9	NBR	W4	80
442–454	9	NBR	W5	80
442–454	9	SILICONE	W4	200
442–454	9	SILICONE	W5	200
442–454	13	EPDM	W4	100
442–454	13	EPDM	W5	100
442–454	13	NBR	W4	80
442–454	13	NBR	W5	80
442–454	13	SILICONE	W4	200
442–454	13	SILICONE	W5	200
442–454	16	EPDM	W4	100
442–454	16	EPDM	W5	100
442–454	16	NBR	W4	80
442–454	16	NBR	W5	80
442–454	16	SILICONE	W4	200
442–454	16	SILICONE	W5	200
450–462	8	EPDM	W4	100
450–462	8	EPDM	W5	100
450–462	8	NBR	W4	80
450–462	8	NBR	W5	80
450–462	8	SILICONE	W4	200
450–462	8	SILICONE	W5	200
450–462	11	EPDM	W4	100
450–462	11	EPDM	W5	100
450–462	11	NBR	W4	80
450–462	11	NBR	W5	80
450–462	11	SILICONE	W4	200
450–462	11	SILICONE	W5	200
450–462	17	EPDM	W4	100
450–462	17	EPDM	W5	100
450–462	17	NBR	W4	80
450–462	17	NBR	W5	80
450–462	17	SILICONE	W4	200
450–462	17	SILICONE	W5	200
477–489	8	EPDM	W4	100
477–489	8	EPDM	W5	100
477–489	8	NBR	W4	80
477–489	8	NBR	W5	80
477–489	8	SILICONE	W4	200
477–489	8	SILICONE	W5	200
477–489	11	EPDM	W4	100
477–489	11	EPDM	W5	100
477–489	11	NBR	W4	80
477–489	11	NBR	W5	80
477–489	11	SILICONE	W4	200
477–489	11	SILICONE	W5	200
477–489	17	EPDM	W4	100
477–489	17	EPDM	W5	100
477–489	17	NBR	W4	80
477–489	17	NBR	W5	80
477–489	17	SILICONE	W4	200
477–489	17	SILICONE	W5	200
487–499	11	EPDM	W4	100
487–499	11	EPDM	W5	100
487–499	11	NBR	W4	80
487–499	11	NBR	W5	80
487–499	11	SILICONE	W4	200
487–499	11	SILICONE	W5	200
487–499	17	EPDM	W4	100
487–499	17	EPDM	W5	100
487–499	17	NBR	W4	80
487–499	17	NBR	W5	80
487–499	17	SILICONE	W4	200
487–499	17	SILICONE	W5	200

OD (mm)
265–277
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
265–277
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
265–277
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
265–277
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
265–277
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
265–277
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
15
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
15
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
15
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
15
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
15
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
15
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
271–283
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
271–283
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
271–283
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
15
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
15
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
15
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
15
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
15
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
15
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
279–291
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
279–291
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
279–291
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
292–304
Pressure (bar)
15
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
292–304
Pressure (bar)
15
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
292–304
Pressure (bar)
15
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
292–304
Pressure (bar)
15
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
292–304
Pressure (bar)
15
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
292–304
Pressure (bar)
15
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
298–310
Pressure (bar)
19
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
298–310
Pressure (bar)
19
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
298–310
Pressure (bar)
19
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
298–310
Pressure (bar)
19
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
298–310
Pressure (bar)
19
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
298–310
Pressure (bar)
19
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
310–322
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
310–322
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
310–322
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
320–332
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
320–332
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
320–332
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
329–341
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
329–341
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
329–341
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
338–350
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
338–350
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
338–350
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
12
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
12
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
12
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
12
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
12
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
12
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
349–361
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
349–361
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
349–361
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
359–371
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
359–371
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
359–371
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
359–371
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
359–371
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
359–371
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
372–384
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
372–384
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
372–384
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
379–391
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
379–391
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
379–391
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
379–391
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
379–391
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
379–391
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
18
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
18
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
394–406
Pressure (bar)
18
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
18
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
394–406
Pressure (bar)
18
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
394–406
Pressure (bar)
18
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
402–414
Pressure (bar)
13
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
402–414
Pressure (bar)
13
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
402–414
Pressure (bar)
13
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
402–414
Pressure (bar)
13
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
402–414
Pressure (bar)
13
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
402–414
Pressure (bar)
13
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
410–422
Pressure (bar)
9
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
410–422
Pressure (bar)
9
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
410–422
Pressure (bar)
9
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
410–422
Pressure (bar)
9
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
410–422
Pressure (bar)
9
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
410–422
Pressure (bar)
9
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
410–422
Pressure (bar)
13
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
410–422
Pressure (bar)
13
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
410–422
Pressure (bar)
13
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
410–422
Pressure (bar)
13
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
410–422
Pressure (bar)
13
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
410–422
Pressure (bar)
13
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
410–422
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
410–422
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
410–422
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
410–422
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
410–422
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
410–422
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
425–437
Pressure (bar)
9
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
425–437
Pressure (bar)
9
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
425–437
Pressure (bar)
9
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
425–437
Pressure (bar)
9
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
425–437
Pressure (bar)
9
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
425–437
Pressure (bar)
9
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
425–437
Pressure (bar)
13
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
425–437
Pressure (bar)
13
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
425–437
Pressure (bar)
13
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
425–437
Pressure (bar)
13
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
425–437
Pressure (bar)
13
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
425–437
Pressure (bar)
13
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
425–437
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
425–437
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
425–437
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
425–437
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
425–437
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
425–437
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
433–445
Pressure (bar)
9
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
433–445
Pressure (bar)
9
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
433–445
Pressure (bar)
9
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
433–445
Pressure (bar)
9
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
433–445
Pressure (bar)
9
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
433–445
Pressure (bar)
9
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
433–445
Pressure (bar)
13
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
433–445
Pressure (bar)
13
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
433–445
Pressure (bar)
13
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
433–445
Pressure (bar)
13
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
433–445
Pressure (bar)
13
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
433–445
Pressure (bar)
13
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
433–445
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
433–445
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
433–445
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
433–445
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
433–445
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
433–445
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
442–454
Pressure (bar)
9
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
442–454
Pressure (bar)
9
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
442–454
Pressure (bar)
9
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
442–454
Pressure (bar)
9
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
442–454
Pressure (bar)
9
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
442–454
Pressure (bar)
9
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
442–454
Pressure (bar)
13
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
442–454
Pressure (bar)
13
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
442–454
Pressure (bar)
13
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
442–454
Pressure (bar)
13
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
442–454
Pressure (bar)
13
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
442–454
Pressure (bar)
13
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
442–454
Pressure (bar)
16
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
442–454
Pressure (bar)
16
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
442–454
Pressure (bar)
16
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
442–454
Pressure (bar)
16
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
442–454
Pressure (bar)
16
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
442–454
Pressure (bar)
16
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
450–462
Pressure (bar)
8
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
450–462
Pressure (bar)
8
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
450–462
Pressure (bar)
8
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
450–462
Pressure (bar)
8
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
450–462
Pressure (bar)
8
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
450–462
Pressure (bar)
8
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
450–462
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
450–462
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
450–462
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
450–462
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
450–462
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
450–462
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
450–462
Pressure (bar)
17
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
450–462
Pressure (bar)
17
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
450–462
Pressure (bar)
17
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
450–462
Pressure (bar)
17
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
450–462
Pressure (bar)
17
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
450–462
Pressure (bar)
17
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
477–489
Pressure (bar)
8
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
477–489
Pressure (bar)
8
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
477–489
Pressure (bar)
8
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
477–489
Pressure (bar)
8
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
477–489
Pressure (bar)
8
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
477–489
Pressure (bar)
8
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
477–489
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
477–489
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
477–489
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
477–489
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
477–489
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
477–489
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
477–489
Pressure (bar)
17
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
477–489
Pressure (bar)
17
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
477–489
Pressure (bar)
17
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
477–489
Pressure (bar)
17
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
477–489
Pressure (bar)
17
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
477–489
Pressure (bar)
17
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
487–499
Pressure (bar)
11
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
487–499
Pressure (bar)
11
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
487–499
Pressure (bar)
11
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
487–499
Pressure (bar)
11
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
487–499
Pressure (bar)
11
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
487–499
Pressure (bar)
11
Gasket
SILICONE
Quality
W5
T max (°C)
200
OD (mm)
487–499
Pressure (bar)
17
Gasket
EPDM
Quality
W4
T max (°C)
100
OD (mm)
487–499
Pressure (bar)
17
Gasket
EPDM
Quality
W5
T max (°C)
100
OD (mm)
487–499
Pressure (bar)
17
Gasket
NBR
Quality
W4
T max (°C)
80
OD (mm)
487–499
Pressure (bar)
17
Gasket
NBR
Quality
W5
T max (°C)
80
OD (mm)
487–499
Pressure (bar)
17
Gasket
SILICONE
Quality
W4
T max (°C)
200
OD (mm)
487–499
Pressure (bar)
17
Gasket
SILICONE
Quality
W5
T max (°C)
200

IBWR 320-332 A2E12

Details

Downloads
